Hikvision Network Camera Families and Finding the Correct Firmware
Update 6th June 2018 - HikVision reorganised their European Download Portal at the end of May AND renamed some of their camera families AND introduced new camera families. So, please follow this link to our new post on finding the latest HikVision firmware for your camera.
Hikvision offer a huge range of cameras with hundreds of variants available for purchase - it's no wonder there's confusion about which cameras are from the newest family and whether the camera you're interested in is the most up to date model available.
Each new range introduces new features and better sensors. But also, as you would expect with any manufacturer, development only continues with the current model range. Older ranges stop getting updated except for the bare minimum security updates.
With Hikvision especially, the price difference between cameras from the newest series and the cameras which they supersede is minimal so we recommend sticking to the new series for the sake of future proofing your system.
With that being said, we still get orders for R6 series cameras despite there being no benefit to buying these cameras.
-I and -K series NVR are H.265+ ready, a function only available in the newest G1 family (EasyIP 3.0) cameras, so why not utilize this?
It's important to know which family your camera comes from in order to be able to find firmware for your camera and know how old your camera is.
At the bottom of this thread we'll cover where you can find the most up to date firmware for your camera.
Below is a run down of the main camera families from Hikvision with the newest series at the top.
____________________________________________________________________
G1 Family (EasyIP 3.0)
Release Year: 2017
Resolutions: 3MP, 5MP and 8MP
____________________________________________________________________
Dome
3MP - DS-2CD2135FWD-I/DS-2CD2135FWD-IS
5MP - DS-2CD2155FWD-I/DS-2CD2155FWD-IS
8MP - DS-2CD2185FWD-I
--------------------------------------------------------------------------------------
Mini Dome
3MP - DS-2CD2535FWD-I/DS-2CD2535FWD-IS/DS-2CD2535FWD-IWS(coming soon)
5MP - DS-2CD2555FWD-I/DS-2CD2555FWD-IS/DS-2CD2555FWD-IWS(coming soon)
8MP - DS-2CD2585FWD-I/DS-2CD2585FWD-IS(coming soon)/DS-2CD2585FWD-IWS(coming soon)
--------------------------------------------------------------------------------------
Motorised Zoom Dome
3MP - DS-2CD2735FWD-IZ/DS-2CD2735FWD-IZS
5MP - DS-2CD2755FWD-IZS
8MP - DS-2CD2785FWD-IZS
--------------------------------------------------------------------------------------
Turret
3MP - DS-2CD2335FWD-I
5MP - DS-2CD2355FWD-I
8MP - DS-2CD2385FWD-I
--------------------------------------------------------------------------------------
Motorised Zoom Turret
3MP - DS-2CD2H35FWD-IZS
5MP - DS-2CD2H55FWD-IZS
8MP - DS-2CD2H85FWD-IZS
--------------------------------------------------------------------------------------
Mini Bullet
3MP - DS-2CD2035FWD-I
5MP - DS-2CD2055FWD-I
8MP - DS-2CD2085FWD-I
--------------------------------------------------------------------------------------
EXIR 2T Bullet
3MP (I5) - DS-2CD2T35FWD-I5
5MP (I5) - DS-2CD2T55FWD-I5
5MP (I8) - DS-2CD2T55FWD-I8
8MP (I5) - DS-2CD2T85FWD-I5
8MP (I8) - DS-2CD2T85FWD-I8
--------------------------------------------------------------------------------------
Motorised Zoom Bullet
3MP - DS-2CD2635FWD-IZS
5MP - DS-2CD2655FWD-IZS
8MP - DS-2CD2685FWD-IZS
--------------------------------------------------------------------------------------
Indoor Cube
5MP - DS-2CD2455FWD-IW
--------------------------------------------------------------------------------------
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
_______________________________________________________________
R0 Family and R6 Family
Release Year:
R0 - 2013
R6 - 2015
Resolutions:
R0 - 1.3MP and 3MP
R6 - 2MP and 4MP
____________________________________________________________________
Dome
R0
1.3MP - DS-2CD2112-I/DS-2CD2112F-I
3MP - DS-2CD2132-I/DS-2CD2132F-I/DS-2CD2132F-IS
R6
2MP - DS-2CD2122FWD-I
4MP - DS-2CD2142FWD-I/DS-2CD2142FWD-IS/DS-2CD2142FWD-IWS
--------------------------------------------------------------------------------------
Mini Dome
R0
1.3MP - DS-2CD2512F-IWS
3MP - DS-2CD2532F-I/DS-2CD2532F-IS/DS-2CD2532F-IWS
R6
2MP - DS-2CD2522FWD-I
4MP - DS-2CD2542FWD-I/DS-2CD2542FWD-IS
--------------------------------------------------------------------------------------
Varifocal Dome
R0
1.3MP - DS-2CD2712F-I/DS-2CD2712F-IS
3MP - DS-2CD2732F-I/DS-2CD2732F-IS
R6
2MP - DS-2CD2722FWD-I/DS-2CD2722FWD-IS/DS-2CD2722FWD-IZS
4MP - DS-2CD2742FWD-I/DS-2CD2742FWD-IS/DS-2CD2742FWD-IZS
--------------------------------------------------------------------------------------
Turret
R0
1.3MP - DS-2CD2312-I
3MP - DS-2CD2332-I
R6
2MP - DS-2CD2322WD-I
4MP - DS-2CD2342WD-I
--------------------------------------------------------------------------------------
Mini Bullet
R0
1.3MP - DS-2CD2012-I
3MP - DS-2CD2032-I/DS-2CD2032F-IW
R6
2MP - DS-2CD2022WD-I/DS-2CD2022F-IW/DS-2CD2022F-I
4MP - DS-2CD2042WD-I
--------------------------------------------------------------------------------------
2T EXIR Bullet
R0
3MP (I5) - DS-2CD2T32-I5
R6
4MP (I5) - DS-2CD2T42WD-I5
4MP (I8) - DS-2CD2T42WD-I8
--------------------------------------------------------------------------------------
EXIR Bullet
R0
1.3MP - DS-2CD2212-I5
3MP - DS-2CD2232-I5
--------------------------------------------------------------------------------------
Varifocal Bullet
R0
3MP - DS-2CD2632F-I/DS-2CD2632F-IS
R6
2MP - DS-2CD2622FWD-I/DS-2CD2622FWD-IS/DS-2CD2622FWD-IZS
4MP - DS-2CD2642FWD-I/DS-2CD2642FWD-IS/DS-2CD2642FWD-IZS
--------------------------------------------------------------------------------------
Indoor Cube
R0
3MP - DS-2CD2432F-IW
R6
4MP - DS-2CD2442FWD-IW
--------------------------------------------------------------------------------------
Hopefully this list will help you find the newest cameras on the market, or, if you already own Hikvision cameras help you figure out which family your camera belongs to. G1 Family (EasyIP 3.0)
Release Year: 2017
Resolutions: 3MP, 5MP and 8MP
____________________________________________________________________
Dome
3MP - DS-2CD2135FWD-I/DS-2CD2135FWD-IS
5MP - DS-2CD2155FWD-I/DS-2CD2155FWD-IS
8MP - DS-2CD2185FWD-I
--------------------------------------------------------------------------------------
Mini Dome
3MP - DS-2CD2535FWD-I/DS-2CD2535FWD-IS/DS-2CD2535FWD-IWS(coming soon)
5MP - DS-2CD2555FWD-I/DS-2CD2555FWD-IS/DS-2CD2555FWD-IWS(coming soon)
8MP - DS-2CD2585FWD-I/DS-2CD2585FWD-IS(coming soon)/DS-2CD2585FWD-IWS(coming soon)
--------------------------------------------------------------------------------------
Motorised Zoom Dome
3MP - DS-2CD2735FWD-IZ/DS-2CD2735FWD-IZS
5MP - DS-2CD2755FWD-IZS
8MP - DS-2CD2785FWD-IZS
--------------------------------------------------------------------------------------
Turret
3MP - DS-2CD2335FWD-I
5MP - DS-2CD2355FWD-I
8MP - DS-2CD2385FWD-I
--------------------------------------------------------------------------------------
Motorised Zoom Turret
3MP - DS-2CD2H35FWD-IZS
5MP - DS-2CD2H55FWD-IZS
8MP - DS-2CD2H85FWD-IZS
--------------------------------------------------------------------------------------
Mini Bullet
3MP - DS-2CD2035FWD-I
5MP - DS-2CD2055FWD-I
8MP - DS-2CD2085FWD-I
--------------------------------------------------------------------------------------
EXIR 2T Bullet
3MP (I5) - DS-2CD2T35FWD-I5
5MP (I5) - DS-2CD2T55FWD-I5
5MP (I8) - DS-2CD2T55FWD-I8
8MP (I5) - DS-2CD2T85FWD-I5
8MP (I8) - DS-2CD2T85FWD-I8
--------------------------------------------------------------------------------------
Motorised Zoom Bullet
3MP - DS-2CD2635FWD-IZS
5MP - DS-2CD2655FWD-IZS
8MP - DS-2CD2685FWD-IZS
--------------------------------------------------------------------------------------
Indoor Cube
5MP - DS-2CD2455FWD-IW
--------------------------------------------------------------------------------------
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
_______________________________________________________________
R0 Family and R6 Family
Release Year:
R0 - 2013
R6 - 2015
Resolutions:
R0 - 1.3MP and 3MP
R6 - 2MP and 4MP
____________________________________________________________________
Dome
R0
1.3MP - DS-2CD2112-I/DS-2CD2112F-I
3MP - DS-2CD2132-I/DS-2CD2132F-I/DS-2CD2132F-IS
R6
2MP - DS-2CD2122FWD-I
4MP - DS-2CD2142FWD-I/DS-2CD2142FWD-IS/DS-2CD2142FWD-IWS
--------------------------------------------------------------------------------------
Mini Dome
R0
1.3MP - DS-2CD2512F-IWS
3MP - DS-2CD2532F-I/DS-2CD2532F-IS/DS-2CD2532F-IWS
R6
2MP - DS-2CD2522FWD-I
4MP - DS-2CD2542FWD-I/DS-2CD2542FWD-IS
--------------------------------------------------------------------------------------
Varifocal Dome
R0
1.3MP - DS-2CD2712F-I/DS-2CD2712F-IS
3MP - DS-2CD2732F-I/DS-2CD2732F-IS
R6
2MP - DS-2CD2722FWD-I/DS-2CD2722FWD-IS/DS-2CD2722FWD-IZS
4MP - DS-2CD2742FWD-I/DS-2CD2742FWD-IS/DS-2CD2742FWD-IZS
--------------------------------------------------------------------------------------
Turret
R0
1.3MP - DS-2CD2312-I
3MP - DS-2CD2332-I
R6
2MP - DS-2CD2322WD-I
4MP - DS-2CD2342WD-I
--------------------------------------------------------------------------------------
Mini Bullet
R0
1.3MP - DS-2CD2012-I
3MP - DS-2CD2032-I/DS-2CD2032F-IW
R6
2MP - DS-2CD2022WD-I/DS-2CD2022F-IW/DS-2CD2022F-I
4MP - DS-2CD2042WD-I
--------------------------------------------------------------------------------------
2T EXIR Bullet
R0
3MP (I5) - DS-2CD2T32-I5
R6
4MP (I5) - DS-2CD2T42WD-I5
4MP (I8) - DS-2CD2T42WD-I8
--------------------------------------------------------------------------------------
EXIR Bullet
R0
1.3MP - DS-2CD2212-I5
3MP - DS-2CD2232-I5
--------------------------------------------------------------------------------------
Varifocal Bullet
R0
3MP - DS-2CD2632F-I/DS-2CD2632F-IS
R6
2MP - DS-2CD2622FWD-I/DS-2CD2622FWD-IS/DS-2CD2622FWD-IZS
4MP - DS-2CD2642FWD-I/DS-2CD2642FWD-IS/DS-2CD2642FWD-IZS
--------------------------------------------------------------------------------------
Indoor Cube
R0
3MP - DS-2CD2432F-IW
R6
4MP - DS-2CD2442FWD-IW
--------------------------------------------------------------------------------------
Firmware is found at Hikvision's European Download Portal and is sectioned into subcategories by series name so it can be a struggle to find your firmware without knowing which family your camera belongs to. The below links will take you to the correct firmware folder for your camera:
It's equally important to keep your NVR's firmware up to date!
If you're not sure how to update your firmware, don't fret , you can follow our tutorial here!
As always, if you have any questions then please let us know...
Please find this info available in a handy video below!
